CV5/A3.. AV-Composite - 5 x Video + 3 x Audio - long distance

$COMPOSITE Cable, \"\"High Resolution\"\"$

SKU: CV5A3H

stock:

€27.10 / m

Incl. 19% Tax, excl. Shipping Cost

incl. German VAT plus postage

twisting	3 x video V10/48AF (RGB) + 2 x video V06/28AF (HS,VS) + 3 x audio
taping	fleece
outer jacket	PVC or FRNC
overall diameter	20 mm

cond. construction	solid tinned copper wire, Ø 0.50 mm²
cond. cross section	0.2 mm²
insulation	PE
core arrangement	2 cores twisted to a pair
shielding	AL/PET-foil + tinned drain wire, 0.5 mm Ø
outer jacket	PVC resp. LSZH, 2.7 mm Ø, grey, red and blue
conductor resistance	< 95 Ω/km
capacitance	95 pF/m
insulation resistance	> 10 GΩ x km

type	V1.0/4.8AF
inner conductor	solid bare copper, 1.0 mm Ø
insulation	Foam-Skin-PE, 4.8 mm Ø
shielding	AL/PET/AL double-layer foil + tinned copper braid (95% coverage)
outer jacket	PVC resp. LSZH, 7.0 mm Ø, red, green, blue
characteristic impedance	75 Ω
capacitance	57 pF/m
velocity of propagation	83 %
conductor resistance	21.8 Ω/km
shield resistance	5.8 Ω/km
attenuation [dB/100m]
1 MHz	0.8
5 MHz	1.6
10 MHz	2.1
100 MHz	6.2
200 MHz	8.9
500 MHz	14.6
800 MHz	18.5
1000 MHz	20.9
1500 MHz	26

type	V0.6/2.8AF
inner conductor	solid bare copper, 0.60 mm Ø
insulation	Foam-Skin-PE, 4.8 mm Ø
shielding	AL/PET/AL double-layer foil + tinned copper braid (95% coverage)
outer jacket	PVC resp. LSZH, 4.5 mm Ø, black, white
characteristic impedance	75 Ω
capacitance	61 pF/m
condctor resistance	60.5 Ω/km
shield resistance	12.8 Ω/km
attenuation [dB/100m]
1 MHz	1.2
5 MHz	2.7
10 MHz	3.8
100 MHz	11
200 MHz	15.3
500 MHz	25
800 MHz	31.8
1000 MHz	35.6
1500 MHz	43.6
